    CE Hydraulic Winch Diagram For Wrecker DJ010D DJ3D DJ5

    Ask Lasest Price
    Brand Name : Elephant Fluid Power
    Model Number : DJ010D
    Price : Negotiable
    Payment Terms : TT,Paypal,Western Union
    Supply Ability : 30000 sets per month
    Delivery Time : 3-5 days
    MOQ : 1 piece
    • Product Details
    • Company Profile

    CE Hydraulic Winch Diagram For Wrecker DJ010D DJ3D DJ5

    Factory Price OEM Quality 2T-20T Hydraulic Winches For Rescue Truck
    Elephant Fluid Power specializes in designing and manufacturing hydraulic winches, hydraulic motors and planetary gearboxes for more than twenty years. We are one of the leading Construction Machinery Accessory Suppliers in Asia. Customizing to optimize customers’ ingenious equipment designs is our way to stay alive robustly in the market. Over 26 years, driven by the commitment of always innovating for satisfying customers’ needs, we have developed a wide range of product line based on our self-developed technologies. The wide spectrum of products, but each correlating intimately, contains hydraulic and electric winches, planetary gearboxes, slewing drives, transmission drives, hydraulic motors, pumps and hydraulic systems.
    Technical Data:
    Model: GW Series
    Pull Force: 1000 - 18000kgs
    Rope Speed: 0-40m/min

    Special Features
    1) One-or two-stage planetary gearboxes, smooth operation and reasonable structure.
    2) Normally closed friction type brake, high braking torque, safe and reliable operating.
    3) Small volume, compact structure and high transmission efficiency.
    4) Radial piston hydraulic motor with long life operating.
    5) Mounting frame is available on request.
    6) Balance valve, shuttle valve, limit switch and other accessories are also available on request.


    ModelW.L.L.
    1st layer
    W.L.L.
    top layer
    Rope
    Speed
    Rope
    diam.
    Capacity of
    Rope
    Working
    Pressure
    Max Supply
    Oil Flow
    kgfkgfm/minmmmMpaL/min
    GW100010008603010601640
    GW2000200016803012501670
    GW3000300025263515651680
    GW40004000333535166517100
    GW50005000416740208716160
    GW6000600049224021.56816190
    GW800080006698402410016260
    GW1000010000784640289016310
    GW120001200010080303017517270
    GW15000150009880253415020240
    GW180001800014700303814318360

    products

    Elephant Fluid Power is a professional manufacturer and distributorof Hydraulic components which are widely applied to engineer
    construction, agriculture, marine, mining, etc. All of the products areof High quality. Including the Hydraulic pump, hydraulic motor, Pumpspare parts,Motor spare parts, Hydraulic Valve, Steering Unit...Elephant Fluid Power Technical team has many years of operationand service experience,Provide customers with professional
    hydraulic system solutions,Quality assurance of quality products,We have many years in hydraulic system products,1-7 days, fixedsales engineer, agreement specific delivery period, Years of industryexperience, sales, repairs, commissioning, maintenance, Superfastone-stop professional service, Provide a technical response within2 hours of the standard warranty,Effectively guarantee the quality ofhydraulic products, Worry-free delivery time 1300 kinds in stock,One-stop service, directly with the manufacturer, Provide completehydraulic system solutions,Comprehensive guidance to providetechnical services within 1 working day,Rigorous processing andexcellent quality.
