    Char Lynn 10000 Hydraulic Orbit Motor High Torque Low Speed 57.4 Cu

    Ask Lasest Price
    Brand Name : Hanjiu
    Model Number : BMER
    Price : Negotiable
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 30000 Set/month
    Delivery Time : 20-30 Days
    • Product Details
    • Company Profile

    Char Lynn 10000 Hydraulic Orbit Motor High Torque Low Speed 57.4 Cu

    119-1031-003 Hydraulic Orbit Motor Low Speed Motor 57.4 Cu/In Charlynn 10000 Series Hydraulic Motor For Port Equipment

    Product details:

    BK10 series static wet hydraulic brake is suitable for lower speed appliion of scissors type aerial work platform and
    agricultural machinery and others with wheel mounting. The feature:
    * The output shaft adopts the same heavy duty roller bearing in front and behind, which is bigger ability on radial load.
    * It adopts optimized disc brake piece and spring load, for reliable braking and good endurance.
    * Optimizing piston and loading mechanism, to provide the minimum dimension of wheel connection method.
    * With double braking release port, in order to discharge the braking cylinder gas or external brake fluid.
    * Big braking torque, suitable for static braking

    Appliion:

    • Boring
    • Industrial
    • Metal Forming
    • Port Equipment
    • Saw Mill

    Specifiions


    Main Specifiion
    TypeBMK10BMK10BMK10BMK10
    345480665940
    Geometric displacement345480665940
    (cm3 /rev.)
    Main speed(rpm)cont.501354254179
    int.784552396279
    Max torque N.Mcont.1040147520852700
    int.1390196526103440
    Max pressure drop (Mpa)cont.20202020
    int.27.527.527.527.5
    Weight (kg)26.326.827.328


    Model 119-1031
    57.4 cu in displ
    PSI 2750 cont
    PSI 3500 int
    PSI 3750 peak
    Torque 23,910 in lbs cont
    Torque 30,460 in lbs int
    179 RPM at 45 GPM
    279 RPM at 70 GPM
    Rotation reversible
    Mount SAE C 4 bolt
    Shaft 2-1/4" dia x 4.49" w/1/2" keyway
    Ports SAE 16
    drain SAE 6
    Size 16-1/4" x 6" x 6"
    weight 110 lbs.

    Eaton similar type motors are available we belows:

    • J (129-) HANJIU BMM
    • H (101-) HANJIU BMPH
    • S (103-) HANJIU BMRS
    • T (158-) HANJIU BMRS
    • W (162-) HAJJIU BMRW
    • 2000 (104-, 105-, 106-, 193-) HANJIU BMK2
    • 4000 (109-, 110-, 111-) HANJIU BMK4
    • 6000 (112-, 113-, 114-) HANJIU BMK6
    • 10000 (119-) HANJIU BMK10

    At present, most popular Brands in Hydraulics are Danfoss, Char Lynn, M+S, HANJIU, each with its own merits, however the reason why more and more clients choose HANJIU is because it has obvious advantages over other brands in terms of delivery, service, quality and profit rate.
