Concrete Pump Maintain Repair Parts SPV23 PV23 Hydraulic Pump Factory Price OEM Quality

Elephant Fluid Power Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Concrete Pump Maintain Repair Parts SPV23 PV23 Hydraulic Pump Factory Price OEM Quality from wholesalers

    Buy cheap Concrete Pump Maintain Repair Parts SPV23 PV23 Hydraulic Pump Factory Price OEM Quality from wholesalers
    • Buy cheap Concrete Pump Maintain Repair Parts SPV23 PV23 Hydraulic Pump Factory Price OEM Quality from wholesalers
    • Buy cheap Concrete Pump Maintain Repair Parts SPV23 PV23 Hydraulic Pump Factory Price OEM Quality from wholesalers
    • Buy cheap Concrete Pump Maintain Repair Parts SPV23 PV23 Hydraulic Pump Factory Price OEM Quality from wholesalers
    • Buy cheap Concrete Pump Maintain Repair Parts SPV23 PV23 Hydraulic Pump Factory Price OEM Quality from wholesalers
    • Buy cheap Concrete Pump Maintain Repair Parts SPV23 PV23 Hydraulic Pump Factory Price OEM Quality from wholesalers
    • Buy cheap Concrete Pump Maintain Repair Parts SPV23 PV23 Hydraulic Pump Factory Price OEM Quality from wholesalers

    Concrete Pump Maintain Repair Parts SPV23 PV23 Hydraulic Pump Factory Price OEM Quality

    Ask Lasest Price
    Brand Name : Elephant Fluid Power
    Model Number : SPV23/PV23
    Price : More favorable price
    Payment Terms : TT,Paypal,Western Union
    Supply Ability : 30000 sets per month
    Delivery Time : 3-5 days
    • Product Details
    • Company Profile

    Concrete Pump Maintain Repair Parts SPV23 PV23 Hydraulic Pump Factory Price OEM Quality

    Concrete Pump Maintain Repair Parts SPV23 PV23 Hydraulic Pump Factory Price OEM Quality
    Elephant fluid power Co.,ltd manufactures Concrete Pump Maintain Repair Parts SPV23 PV23 Hydraulic Pump Factory Price OEM Quality,
    good quality,competitive price,one year warranty,fast lead time.
    Technical Data:
    Nominal pressure 210 bars, Maximum pressure 350 bars.

    The Sauer PV axial piston variable displacement pumps, Series 20, are of swash plate construction with variable flow capability suitable for hydrostatic transmissions with closed circuit. The flow rate is proportional to the pumps driven speed displacement, which, in turn, is determined by the swash plate angle. The latter is infinitely adjustable between zero and maximum displacement. Flow direction is reserved by titling the swash plate to the opposite side of the neutral or zero displacement position. These units and parts are fit, form and function replacements for Sauer-Sundstrand series 20 components.

    - Suitable for a variety of appliCAATions
    - Multiple displacements and options available
    - 8 different frame sizes
    - Engineered to provide a long service life and reliability
    - Fixed displacement motor can be operated in either direction of rotation
    - Multiple drive shaft options and control options
    - Heavy duty bearings and shafts
    - Easily serviceable
    - Replacement parts also available
    - Direct replacements for Sauer-Sundstrand
    Table of Values:
    SizeDimensionSauer-DANFOSS PV pump
    PV20PV21PV22PV23PV24PV25PV26PV27
    Max. displacementcm333,351,669,889,0118,7165,8227,3333,7
    Max. flowdm3min-1119,5159,9196,1230,5278,9348,1429,59557,2
    4641488
    Charge pumpcm312,312,318,0318,0318,832,832,865,5
    Max. pressureMPa35
    Nominal pressureMPa21
    Max. pressure of controlMPa3,5
    Charge pressureMPa0,8 - 2,0
    Max. pressure in caseMPa0,25 continuous 0,5 intermittent
    Maximum speed +min-135903100281025902350210018901670
    Minimum speedmin-1500
    Nominal speedmin-11500
    Kinematic viscosity range of working fluid
    - starting
    - operating
    - optimum

    1000
    12 - 600
    25 - 35
    mm2s-1
    Kind of working fluidmineral oil
    Operating temperatureoC- 40 to + 50
    Max. temperature of working fluid in tankoC80
    Purity of working fluidµm10
    Direction of shaft rotationclockwise or counter clockwise
    Maximum swash plate angleo± 18 o
    Weightkg45556378124164212270
    We,Elephant Fluid Power can supply hydraulic pumps,hydraulic motors for concrete pump,concrete mixer truck and excavator ,good quality,fast lead time,one year warranty,is your best choice for hydraulic products.
    Our main products models :
    RexrothA2F12/23/28/55/80/107/160/200/225/250/335/500
    A2FO10/12/16/23/28/32/45/56/63/80/90/107/125/160/180/200/250/500
    A7V28/55/80/107/160/225/250/355/500/1000
    A6VM(A7VO)/12/28/55/80/107/160/200/250/355/500
    A4VSO45/71/125/180/250/500/1000
    A4V40/56/71
    A4VG28/40/45/50/56/71/90/125/140/180/250
    A4VTG71/90
    A10VSO10/16/18/28/45/63/71/85/100/140
    A10VG18/28/45/63
    A11VO60/75/95/130/145/160/190/250/260
    KawasakiK3SP36C
    K3V63DT/112DT/140DT/180DT/280DT
    K3VL28/45/60/80/112/140/200
    K3VG63/112/180/280
    K7V63/100
    K7VG180/265
    K5V80/140/160/200
    NV45/50/60/64/70/80/84/90/111/120/137/172/210/237/270
    NX15
    NVK45
    KVC925/930/932
    M2X55/63/96/120/128/146/150/170/210
    M5X130/150/173/180/500
    MX50/80/150/173/200/250/450/500/530/750
    KAYABAMAG150/170
    KYB87
    MSG18P/27P/44P/50P
    MSF series
    KomatsuuHPV 35/55/90/160(PC60/120/200/220/300-3/5)PC400/PC650
    LibherrLPVD 35/45/64/75/90/100/125/140/165/225/250
    FMV075/100
    LMF(V)45/64/75/90/100/125/140
    ToshibaPVB80/92
    PVC80/90
    SG 015/02/025/04/08/12/15/17/20/25
    LinderHPV55/75/105/135/165/210/280
    HPR75/90/100/130/160
    MPR28/45/63/71
    HMR75/105/135/165
    HMF28/35/50/
    BPV35/50/70/100/200
    B2PV35/50/75/105/140/186
    BMF35/55/75/105/140/186/260
    BMV35/55/75/105/135
    BPR55/75/105/140/186/260
    SauerPV90R(L)(M)030/42/55/75/100/130/180/250
    PV42-28/41/51
    SPV15/18
    KRR(LRR)025C/030D/038C/045D
    MR(MS)070/089/227/334
    Eaton3321/3331
    4621/4631
    5421/5431
    78461/78462
    VickerPVE12/21/45
    TA19/MFE19
    PVM 018/020/045/050/057/063/074/081/098/106/131/141
    PVH 57/74/98/131/141
    PVB 5/6/10/15/20/29/45/90
    YukenA10/16/22/37/40/45/56/70/90/100/125/145/220
    A3H16/37/56/71/100/145/180
    ParkerPVP16/23/33/41/48/60/76/100/140
    PV 016/020/023/028/032/040/046/063/080/092/140/180/270
    P2/3-060/075/105/145
    PAVC 33/38/65/100
    HitachiHPV050/102/105/118/135
    HMGC16/32/48
    HMGF35/36/38/57
    TokiwaMKV23/33
    UchidaA10VD17/23/28/40/43/71
    AP2D12/14/18/21/25/28/36/38/42
    A8VO55/59/80/86/107/115/172
    NachiYC35-6
    PVD-2B-32/34/36/38/40/42/45/50
    PVD-3B-54/56/60/66
    PZ-6B-180/220
    PVK-2B-50/505
    PZ-4B-100
    PVD-00B-14/16P
    PVD-1B-23/28/32/34
    HaweV30D95/140/250
    V60
    Italy SamHCV50/70/90/100/125
    H1V55/75/108/160/226
    H2V55/75/108/160/226
    H1C55/75/108/1

    FAQ

    Questions you maybe inquiry

    Q1.What's the appliCAATion for pump?
    Construction equipment Steel factory or Power plant Industrial equipment Related hydraulic system

    Q2.What about the MOQ?
    MOQ:1~300 pcs.

    Q3.Are you manufacturer? And what's the delivery time?
    Yes, we are manufacturer and have our own factory. Generally, its in stock for common models, 25-30 days will be finished and sent to customer in time.

    Q4.If we don't find what we want on your website, what should we do?
    A: You can email us the descriptions and pictures of the products you need, We will check whether we can make it.

    Q5.How about the inspection and Guarantee of products?
    We promise: all products are tested before ship, to confirm it will be working and in good conditions when customers get. Also, we offer 12-month guarantee, if it doesn't work due to quality issue in the period, we will send spares to repair for free.

    Q6. What about your after-sale service?
    If there is any question in use, please talk with your sales manager at any time, so we will know your problems are and help to solve.
